Architectural Film

CQ Chrome Series

CQ Chrome is a PVD E-Beam architectural tint with long fading durability. Nichrome is thinly-deposited on the film to minimize reflection while providing exceptional solar protection properties. It is more affordable than products of similar reflectivity and heat reduction in the industry. Users can lower energy consumption for air-conditioning during hot days with minimal shading of daylight.

Product Features

  • Non-fading, no dyes added
  • Enjoy a cool and comfortable environment without a significantly darker tint
  • A lightly mirrored modern appearance from exterior
  • Affordable interior insulation solution with good shading coefficient
Specifications CQ Chrome 35 CQ Chrome 42 CQ Chrome 50
Visible Light Transmission 36% 45% 55%
Total Solar Transmittance 22% 29% 37%
Total Solar Absorbance 56% 53% 49%
Total Solar Reflectance 22% 18% 14%
Visible Light Reflectance – Interior 26% 18% 13%
Visible Light Reflectance – Exterior 30% 22% 15%
Glare Reduction 60% 50% 39%
Infrared Reduction (1000nm) 81% 75% 68%
Infrared Reduction (1800nm) 95% 94% 93%
Shading Coefficient 0.43 0.50 0.58
Solar Heat Gain Coefficient 0.37 0.43 0.50
Total Solar Energy Rejected 63% 57% 50%
Ultraviolet Reduction 99% 99% 99%

The values presented above are the mean of the data collected during routine quality control for comparison purposes and may vary with different production batches.
