Performance Specifications

Specifications EyeCare 05 EyeCare 15 EyeCare 23 EyeCare 35 EyeCare 50
Visible Light Transmission 7% 12% 22% 34% 55%
Total Solar Transmittance 15% 19% 22% 25% 31%
Total Solar Absorbance 79% 75% 72% 69% 63%
Total Solar Reflectance 6% 6% 6% 6% 6%
Visible Light Reflectance – Interior 6% 6% 7% 7% 7%
Visible Light Reflectance – Exterior 6% 6% 7% 7% 7%
Glare Reduction 92% 87% 76% 62% 39%
Infrared Reduction (1000nm) 99% 99% 99% 99% 99%
Infrared Reduction (1800nm) 90% 90% 90% 90% 90%
Shading Coefficient 0.42 0.45 0.48 0.50 0.55
Solar Heat Gain Coefficient 0.36 0.39 0.42 0.44 0.48
Total Solar Energy Rejected 64% 61% 58% 56% 52%
Ultraviolet Reduction 99% 99% 99% 99% 99%

The values presented above are the mean of the data collected during routine quality control for comparison purposes and may vary with different production batches.
